Burkhard Vogel achieved the degree Diplom-Ingenieur (Telecommunications) from Darmstadt University of Technology, Germany, in 1973. He then decided to follow a general management career path in the high-tech and IT industry in Germany, Switzerland, and Austria. His passion for music and music systems made Mr. Vogel an expert in Phono-Amps and Vinyl Technology. In addition to “Slopes and Levels,” he wrote the RIAA-phono-amp designer guides “The Sound of Silence” and “Balanced Phono-Amps,” rounded up by the triode reference “How to Gain Gain”.
Part I Essentials and the Solutions for OPAs with Slopes of 0.0 dB/dec or -10 dB/dec.- Intro.- Basics of OPA Noise and Gain.- Mathcad Worksheets for Chapter 2.- Non-Inverting OPA Gain Stages.- Mathcad Worksheet for Chapter 4.- Inverting OPA Gain Stages.- Mathcad Worksheets for Chapter 6.- Phono Amp with OPAs.- Mathcad Worksheets for Chapter 8.- Part II Essentials and Solutions for OPAs with Slopes Other Than 0.0 dB/dec or -10.0 dB/dec.- The Correlation Matter.- Mathcad Worksheets for Chapter 10.- OPA Noise Modelling.- Mathcad Worksheets for Chapter 12.- Part III Solutions for a Selection of Classic OPAs.- Noise Traces for the Simulation Model of OPAs: Created with the Example OPA NE5534A.- Mathcad Worksheets for Chapter 14.- Example OPA1611.- Mathcad Worksheets for Chapter 16.- Example NE5532A.- Mathcad Worksheets for Chapter 18.- Example OPA134.- Mathcad Worksheets for Chapter 20.- Example TL071.- Mathcad Worksheets for Chapter 22.- Part IV Special ICs Based on Classic OPA Technology (Balanced in – Single-Ended out) And Summary 1.-...
